13-4
Chapter 13
Cajun P550/P880/P882 Switch User Guide
Figure 13-3. Add IPX RIP Filter Dialog Box
3. Refer to Table 13-2 to modify the Add IPX RIP Filter dialog
box parameters.:
Table 13-2. Add IPX RIP Filters Dialog Box Parameters
Parameter Allows you to...
Interface Select the interface to which this filter will be applied
to RIP packets sent and/or received on the interface.
Precedence Specify the filter precedence (in order of importance)
with 0 equal to most important.
Note: All filters on the same interface, must be
assigned a unique filter precedence.
Start Network Specify the first IPX network number in the range.
End Network Specify the last IPX network number in the range.
Direction Select the direction of the filter from a pull-down
menu. The pull-down filter menu options are:
• Inbound - Apply the filter only to RIP packets
received on the interface.
• Outbound - Apply the filter only to RIP
packets sent on the interface.
• Both - Apply the filter to RIP packets both sent
and received on the interface.
