Avaya Cajun P882 - Manual (Page 181)

Cajun P550/P880/P882 Switch User Guide
Configuring Port Parameters
5-29
4. Refer to Table 5-3 for more information about the Switch Port
dialog box parameters:
5. Select one of the following items listed at the bottom of the
screen for more information about the switch ports:
—
Next/Previous Module – Displays the next or previous
module’s switch port parameters.
—
Modules – Returns you to the Module Information
window.
—
All Module Switch Ports Configuration – Opens the
Switch Port Configuration All Ports window and
configures all ports for the selected module.
V
iewing Switch
Port Parameters
Using the CLI
To view switch port parameters using the CLI, enter the following
command from Priv mode:
> show port [{|}
[...,{|}]]
Refer to the Cajun P500/P880/P882 Switch Command Line Interface
Reference Guide for more details about this command.
Table 5-6. Switch Port Parameters
Parameter Definition
Links Opens associated windows.
Port Displays the port associated with the selected
module.
Name Displays the port name and opens the Switch
Port Configuration window for the selected
module.
Port VLAN Displays the port VLAN for the selected
module.
VLAN Classification Displays the port VLAN classification for the
selected module.
Trunk Mode Displays the port’s trunk mode for the
selected module.
Hunt Group Displays the hunt group of which the port is a
member for the selected module.
STAP Mode Displays whether the spanning tree algorithm
protocol is enabled or disabled for the selected
module.
MAC Address Displays the port’s MAC address for the
selected module.
