12-14
Chapter 12
Cajun P550/P880/P882 Switch User Guide
3. Refer to Table 12-5 to configure the Add IPX Static Service
dialog box parameters.:
4. Click CREATE to save your changes, or CANCEL to restore
previous settings.
Creating IPX
Static Services
Using the CLI To create IPX static services using the CLI, enter the following
command in Priv mode:
cajun# ipx service
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about this command.
Table 12-5. IPX Static Service Dialog Box Parameters
Parameter Allows you to ...
Service Name Enter the IPX Static Service name. For example, FS_ENG01. Use
SLIST (NetWare 3.x) or NLIST (NetWare 4.x) to list your current
server names and types from your NetWare server.
Type Enter the service type (in hex) that identifies the type of IPX
static service the server provides.
Well-known service types include:
• Unknown (0)
• Print Queue (3)
• File Server (4)
• Job Server (5)
• Print Server (7)
• Archive Server (9)
• Remote Bridge Server (24)
• Advertising Print Server (47)
Network Enter the IPX Static Service network number.
Node Enter the IPX Static Service node address (in hex).
The format of the node value is aa:bb:cc:dd:ee:ff.
Socket Enter the number (in hex) associated with a running process on
the end node (for example, RIP, NLSP).
Next-Hop Node Enter the MAC address of the next destination through which
the service is reached.
The format of the node value is aa:bb:cc:dd:ee:ff.
Interface Enter the interface that corresponds to the next-hop node.
Hops Enter the number of routers (hops) that the packet must pass
through before reaching the network number associated with
the service.
