Cajun P550/P880/P882 Switch User Guide
Managing Intelligent Multicasting
16-11
3. Select SEARCH to begin the search for the multicast session.
The Multicast Sessions dialog box opens with the search
results (Figure 16-4).
Figure 16-4. Multicast Sessions Dialog Box
4. Refer to Table 16-4 for an explanation of the Multicast
Sessions dialog box parameters:
Table 16-4. Multicast Sessions Dialog Box Parameters
Parameter Definition
Select Select the multicast session.
Session ID Displays the multicast session identifier.
MAC Address Displays the MAC address of the multicast session.
VLAN Displays the VLAN on which the multicast session
exists.
Type Displays the type of multicast session. Options include:
• Learned - Entry is dynamically learned.
• Mgmt - Entry is configured statically by the user.
Client Ports Displays the number of client ports in the multicast
session and opens the Multicast Session Client Ports
dialog box.
Application Displays the active application(s) of the multicast
session. The applications include:
• Mgmt
• IGMP
• LGMP
• CGMP
