Cajun P550/P880/P882 Switch User Guide
Configuring IP Routing
9-3
2. Refer to Table 9-1 for an explanation of the IP Interfaces
dialog box parameters.
Table 9-1. IP Interfaces Dialog Box Parameters
Parameter Allows you to...
Select Select the interface to configure.
State Show the current running condition of the switch.
Options include:
• UP - The interface is active.
• DOWN - The interface is inactive.
Interface Enter an interface name from the interfaces you
have previously configured.
Admin State Shows the administration state of the interface. The
default setting is UP. Options include:
• UP - Indicates an active state.
• DOWN - Indicates an inactive state.
VLAN Select a VLAN associated with the selected interface
from the VLANs you have previously configured.
Network Address Assign an IP address to the VLAN you previously
selected.
Mask Assign a subnet mask for the interface.
MAC Format Specify the MAC format (Ethernet V2 or SNAP).
IP Routing Enable or disable IP Routing on the interface. When
set to Routing/Mgmt, you can both manage the
switch (from the CLI or Web Agent), and configure
IP Routing for the switch. When set to Mgmt Only,
you can manage the switch, however, IP routing is
disabled.
Note: When the interface has a VLAN identified
as Serial-Console, the only valid IP routing
option is Mgmt Only.
RIP Enable or disable RIP for a given interface.
OSPF Enable or disable OSPF for a given interface.
Multicast Protocol Select a multicast protocol to associate with your
interface. Selections include: DVMRP, IGMP, and
None. IGMP is enabled automatically when DVMRP
is selected.
Proxy ARP Enable or disable Proxy ARP on a given interface.
ICMP Redirect Enable or disable Internet Control Message Protocol
(ICMP) Redirect on a given interface.
