Avaya Cajun P882 - Manual (Page 249)

Cajun P550/P880/P882 Switch User Guide
Configuring IP Routing
9-25
Figure 9-9. IP Static ARP Entries Dialog Box
2. Select CREATE. The Add IP Static ARP Entry dialog box opens
(Figure 9-12).
Figure 9-10. Add IP Static ARP Entry Dialog Box
3. Refer to Table 9-7 to configure the Add IP Static ARP Entry
dialog box parameters:
4. Click CREATE to save your changes, or CANCEL to restore
previous settings.
Table 9-7. IP Static ARP Parameters
Parameter Allows you to...
IP Address Enter an IP address to associate with the Static ARP
entry.
MAC Address Enter the MAC address of a node to which you want to
create a static ARP entry.
