Cajun P550/P880/P882 Switch User Guide
Configuring IP Routing
9-31
Figure 9-15. IGMP Interfaces Dialog Box
2. Refer to Table 9-8 to modify an IGMP interface:
Table 9-8. IGMP Interface Parameters
Parameter Allows you to...
Select Select the interface to be modified.
Interface Displays the IP interface that is configured with IGMP.
IP Address Displays the IP address associated with this interface.
Note: This parameter is not configurable from the
IGMP configuration dialog box.
IP Address Mask Displays the subnet mask associated with this interface.
Note: This parameter is not configurable from the
IGMP configuration dialog box.
IGMP Version Select the IGMP Version (1.0 or 2.0) to be associated
with the IGMP interface.
Maximum Groups Enter the number of IGMP Groups that can be active on
this interface. The default value is 32.
Always be Group
Membership Querier Version 1.0 - Select Enable to make this interface the
designated querier. The default is Disable.
Version 2.0 - Select Enable to force this interface to
send queries. The default is Disable which tells the
interface to obey the designated querier election.
Note: Only the designated router will query hosts on
your network.
