Avaya Cajun P882 - Manual (Page 439)

Cajun P550/P880/P882 Switch User Guide
Managing Intelligent Multicasting
16-13
Deleting a Multicast Session Client Port
You can delete an intelligent multicast session client port for either
the web agent or the CLI.
Deleting a
Multicast
Session Client
Port Using the
Web Agent To delete a multicast session client port using the web agent:
1. Select Session Search from the L2 > Intelligent Multicast
group on the web agent window. The Intelligent Multicast
Session Search dialog box opens (Figure 16-3).
2. Select the client port number from the Client Ports column.
The Multicast Session Client Port dialog box opens.
3. Refer to Table 16-5 for an explanation of the Multicast
Session Client Port dialog box parameters:
4. Click DELETE to remove your selected multicast session client
port, or CANCEL to restore previous settings.
* Note: Static (Mgmt) client ports can only be removed through
the Static Sessions dialog box.
Deleting a
Multicast
Session Client
Port Using the
CLI To delete a multicast session client port using the CLI, enter the
following command from Configure mode:
cajun(configure)# clear intelligent-multicast
client-port
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about this command.
Table 16-5. Multicast Session Client Port Dialog Box Parameters
Parameter Definition
Select Select the multicast session client port.
Port Displays the client port number.
Application Displays the application(s) associated with this client port.
The applications are:
• Mgmt
• IGMP
• LGMP
• CGMP
