Cajun P550/P880 /P882 Switch User Guide
Analyzing Network Performance Using RMON and Ethernet Statistics
19-9
2. Refer to Table 19-2 for an explanation of the Port Mirroring
Information dialog box parameters.
Table 19-2. Port Mirroring Information Dialog Box Parameters
3. Select a source port for traffic from the Configure Source
column. The Port Mirroring Configuration dialog box opens
(Figure 19-5).
Figure 19-5. Port Mirroring Configuration Dialog Box
Parameter Definition
Configure Source Select the configuration source port. Provides a link to the
Port Mirroring Configuration dialog box.
Source Port Displays the port under investigation.
Mirror Port Displays the port that transmits mirrored data.
Mirror Port Name Displays the name of the mirror port device.
Piggyback Port Displays the name of the port that is used for bi-directional
port mirroring. When used as a mirror port, it is
unavailable for other uses.
Sampler Type Displays the speed of sampling that is performed for
source port traffic.
Max Packets per Second Displays the maximum number of packets per second that
are served by the mirror port.
