Cajun P550/P880/P882 Switch User Guide
Configuring the OSPF Routing Protocol
11-7
Modifying OSPF Interfaces
You can modify the parameters on an OSPF interface using either
the web agent or the CLI.
Modifying OSPF
Interfaces Using
the Web Agent To modify an OSPF interface using the web agent:
1. Select Interfaces from the Routing > IP > OSPF group in the
web agent window. The OSPF Interfaces dialog box opens
(Figure 11-4).
Note: You must first enable OSPF before you can modify
OSPF interfaces. Refer to Configuring a Static
Route for the PPP Console in Chapter 9 for
information on how to enable OSPF on IP
interfaces.
Figure 11-4. OSPF Interfaces Dialog Box
2. Modify the OSPF Interfaces dialog box parameters. Refer to
Table 11-3 for an explanation of these parameters:
Table 11-3. OSPF Interface Dialog Box Parameters
Parameter Definition
Select Select the OSPF interface to be modified.
Interface Displays IP interface (VLAN) that has OSPF enabled.
Note: This is a read-only field.
IP Address Displays IP address associated with the OSPF interface.
Note: This is a read-only field.
Area Enter the area ID configured for this interface.
DR Priority Enter the decimal value for this interface for DR
priority functionality.
Transit Delay Enter the estimated time (seconds) it takes to transmit
a link state update packet over this interface.
