Cajun P550/P880/P882 Switch User Guide
Managing Intelligent Multicasting
16-23
2. Select Enable from the State field, if it is not already
displayed.
3. Click Apply to complete the operation or Cancel to ignore the
operation.
Enabling the
LGMP Server
Using the CLI To enable the LGMP server using the CLI, enter the following
command from Configure mode:
cajun(configure)# set lgmp server enable
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about this command.
Configuring the LGMP Server
You can configure the LGMP server using either the web agent or
the CLI.
Configuring the
LGMP Server
Using the Web
Agent To configure the LGMP server using the web agent:
1. Select LGMP Snooping from the L2 > Intelligent Multicast
group on the web agent window. The LGMP Server
Configuration dialog box opens (Figure 16-9).
*Note: You must enable intelligent multicasting on a
global basis to activate the LGMP Server. LGMP
serving is only active on VLANs with an IGMP
interface enabled and IGMP snooping globally
enabled.
2. Refer to Table 16-9 to configure the LGMP Server
Configuration dialog box parameters:
Table 16-9. LGMP Server Configuration Dialog Box Parameters
Parameter Definition
Enable State Select to enable or disable LGMP server
configuration. The default value is Disabled.
Proxy Mode Select to enable or disable Proxy mode. Proxy
mode allows the server to send LGMP router
report and leave messages on behalf of neighbor
routers on the same VLAN.
