Cajun P550/P880/P882 Switch User Guide
Configuring IPX Routing
12-15
Deleting IPX Static Service
You can delete an IPX static service using wither the web agent or
the CLI.
Deleting IPX
Static Service
Using the Web
Agent To delete an IPX static service using the web agent:
1. Select Static Services from the Routing > IPX > Configuration
group on the web agent window. The IPX Static Services
dialog box opens (see Figure 12-7).
2. Select the IPX Static Service that you want to remove.
3. Click DELETE to remove the IPX static service, or CANCEL to
keep the IPX Static Service.
Deleting IPX
Static Service
Using the CLI To delete an IPX static service using the CLI, enter the following
command in Priv mode:
cajun(configure)# clear ipx service {
type> |*}
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about this command.
Modifying IPX Static Service
You can modify an IPX static service using either the web agent or
the CLI.
Modifying IPX
Static Service
Using the Web
Agent To modify an IPX static service using the web agent:
1. Select Static Services from the Routing > IPX > Configuration
group on the web agent window. The IPX Static Services
dialog box opens (see Figure 12-7).
2. Select the checkbox for the IPX Static Service that you want
to modify from the Select column.
3. Refer to Table 12-5 to modify the IPX Static Services dialog
box parameters.
