4-12
Chapter 4
Cajun P550/P880/P882 Switch User Guide
Figure 4-7. Spanning Tree Bridge Configuration Dialog Box
5. Refer to Table 4-4 to configure the Spanning Tree Bridge
Configuration parameters:
6. Click APPLY to save your changes, or CANCEL to restore
previous settings.
Table 4-4. Spanning Tree Bridge Configuration Parameters
Parameter Definition
Mode Determines whether spanning tree is enabled or
disabled for this bridge.
Priority STP Priority level for this bridge.
Bridge Max Age Sets the maximum amount of time that this bridge
retains bridging information before discarding. When
the maximum age expires, the bridge assumes it has
lost connection to the network, and sends out
requests to be re-added to the spanning tree.
Bridge Hello
Time Time between generation of BPDUs by the root
bridge.
Bridge Forward
Delay Amount of delay used when a port transitions to the
forwarding state. Set by the root bridge for the
segment.
Note: You must enter a value within the supported
range or the configuration operation will fail.
The supported value range for this parameter
is 10-30.
Max Age Current maximum age for this spanning tree.
Determined by the root bridge.
Hello Time Current hello time for this spanning tree.
Determined by the root bridge.
Forward Delay Current forwarding delay for this spanning tree. Set
by the root bridge.
