11-12
Chapter 11
Cajun P550/P880/P882 Switch User Guide
Deleting OSPF Virtual Links
You can delete OSPF Virtual links using either the web agent or the
CLI.
Deleting OSPF
Virtual Links
Using the Web
Agent To delete an OSPF virtual link using the web agent:
1. Select Virtual Links from the Routing > IP > OSPF group on
the Web Agent window. The OSPF Virtual Links dialog box
opens (Figure 11-5).
2. Select the virtual link that you want to remove.
3. Click DELETE. The virtual link is removed.
Deleting OSPF
Virtual Links
Using the CLI To delete an OSPF virtual link using the CLI, enter the following
command from Configure mode:
Cajun(configure router: ospf)# [no] area
virtual-link
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about this command.
Modifying OSPF Virtual Links
You can modify OSPF virtual links using either the web agent or the
CLI.
Modifying OSPF
Virtual Links
Using the Web
Agent To modify an OSPF virtual link using the web agent:
1. Select Virtual Links from the Routing > IP > OSPF group on
the Web Agent window. The OSPF Virtual Links dialog box
opens (Figure 11-5).
2. Select the virtual link that you want to modify.
3. Refer to Table 11-4 to modify the OSPF Virtual Links dialog
box parameters.
4. Click APPLY to save your changes, or CANCEL to restore
previous settings.
