Cajun P550/P880/P882 Switch User Guide
Configuring Port Parameters
5-31
Figure 5-11. Switch Port Configuration Dialog Box
Refer toTable 5-7 for a description of the Switch Port Configuration
dialog box parameters.
Table 5-7. Switch Port Configuration Parameters
Parameter Definition
Port VLAN Specifies the VLAN assignment for this port.
Trunk Mode Select the appropriate VLAN trunking format to make
the port a trunk, or Clear (default) if you do not want
the port to be a trunk. The trunk formats are IEEE
802.1Q, Multi-Layer, and 3Com.
Frame Tags Select Ignore if you do not want to use received Frame VLAN
tags. Use is the default.
Note: If you select ignore, the received frames are bound to
the port’s default VLAN.
VLAN Binding Select the port’s outgoing VLAN binding type. Refer to
Table 5-8 for more information on VLAN binding options.
