Avaya Cajun P882 - Manual (Page 404)

15-12
Chapter 15
Cajun P550/P880/P882 Switch Configuration Guide
Editing AppleTalk Static Routes
You can edit AppleTalk Static routes using either the web agent or
the CLI.
Editing
AppleTalk Static
Routes Using
the Web Agent To edit an AppleTalk static route using the web agent:
1. Select Static Route from the Routing > AppleTalk >
Configuration group on the web agent window. The
AppleTalk Static Route dialog box opens
(Figure 15-6).
2. Select the checkbox next to the AppleTalk Static Route
that you want to edit from the Select column.
3. Enter the new network range start number in the
Network Range Start field.
4. Enter the new network range end number in the
Network Range End field.
5. Enter the new network number of the next hop for the
static route in the Network Number field.
6. Enter the new node number of the next hop for the static
route in the Node field.
7. Enter the type to be associated with the static route in the
Type field.
8. Select Edit Zone. The Edit AppleTalk Zone dialog box
opens (see Figure 15-4).
9. Enter the new AppleTalk zone network range and click
Add in the Add text field.
10. Click APPLY to save the new zone, or Delete or CANCEL
to ignore the new zone.
Editing
AppleTalk Static
Routes Using
the CLI To edit an AppleTalk static route using the CLI, enter the following
command from Configure mode:
> (config if-:)# appletalk
static cable-range
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about this command.
