Cajun P550/P880/P882 Switch User Guide
Using VLANs, Spanning Tree, Hunt Groups, and VTP Snooping
4-7
Configuring VLAN Parameters
To configure all ports assigned to a VLAN:
1. Select Configuration from the L2 Switching > VLANs group
on the Web Agent window. The VLAN Configuration dialog
box opens (Figure 4-1).
2. Click on the Name of the VLAN whose members you want to
view. The VLAN Switch Ports dialog box opens (Figure 4-3).
Figure 4-3. VLAN Switch Ports Dialog Box
3. Refer to Table 4-2 to configure the VLAN Switch Ports dialog
box parameters:
Table 4-2. VLAN Switch Port Dialog Box Parameters
Parameter Defines...
Port The VLAN switch port.
Name The user-assigned name for this port.
