12-12
Chapter 12
Cajun P550/P880/P882 Switch User Guide
Modifying IPX Static Routes
You can modify IPX static routes form either the web agent or the
CLI.
Modifying IPX
Static Routes
Using the Web
Agent To modify an IPX static route using the web agent:
1. Select Static Routes from the Routing > IPX > Configuration
group on the web agent window. The IPX Static Routes
dialog box opens (see Figure 12-5).
2. Select the checkbox for the IPX static route that you want to
modify from the Select column.
3. Refer to Table 12-4 to modify the IPX Static Route
configuration.
4. Click APPLY to save your changes, or CANCEL to restore
previous settings.
Modifying IPX
Static Routes
Using the CLI To modify an IPX static route using the CLI, enter the following
command Interface mode:
cajun(configure if-)# ipx route
address|range>
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about this command.
