13-2
Chapter 13
Cajun P550/P880/P882 Switch User Guide
2. Refer to Table 13-1 to modify the IPX RIP Interfaces dialog
box parameters:
3. Click APPLY to save your changes, or CANCEL to restore
previous settings.
Table 13-1. IPX RIP Interfaces Dialog Box Parameters
Parameter Allows you to...
Select Select a RIP interface to modify.
Note: This field is displayed in the IPX RIP
Interface dialog box.
Interface Identify the IPX interface associated with the RIP
interface.
Network Number Identify the number of the IPX network
associated with the interface.
Use Interpacket Gap Select Disable if you do not want RIP updates
sent out over an interface to have an interpacket
transmission delay. The default is Enable.
Use Max Packet Size Enable or disable the transmission size of RIP
packets sent out an interface:
• If enabled, RIP packets can contain the
maximum allowed by the MTU of the RIP
interface.
• If disabled, RIP packets are limited to 50
network entries.
Periodic Update
Interval (sec) Specify the length of time for the periodic update
interval.
Aging Interval
Multiplier Specify the length of time that information from
received RIP updates are kept as a multiplier of
the Periodic Update Interval.
Triggered Updates Select Disable to disallow RIP updates to be
immediately transmitted to the network in
response to changes in the network topology. The
default is Enable.
Advertise Default
Route Only Select Enable to allow the advertising of the
default network exclusively (subject to a route to
the default network being known to the switch).
The default is Disable.
Mode Select the one of the following modes for the RIP
interface:
• Talk/Listen - Send and receive
advertisements.
• Talk Only - Send advertisements.
• Listen Only - Receive advertisements.
