Cajun P550/P880/P882 Switch User Guide
Using VLANs, Spanning Tree, Hunt Groups, and VTP Snooping
4-15
4. Select the Bridge Port number from the Bridge Port column.
The Spanning Tree Port Configuration dialog box opens
(Figure 4-9).
Figure 4-9. Spanning Tree Bridge Port Information Dialog Box
5. Refer to Table 4-6 to configure the Spanning Tree Bridge Port
Information dialog box parameters:
Table 4-6. Spanning Tree Bridge Port Information Dialog Box
Parameters
Parameter Definition
Enable Sets whether or not spanning tree is active on this
bridge port.
Priority Sets the port’s priority in the spanning tree algorithm. A
port with a higher priority (lower priority number) is
more likely to be chosen as the primary path in the
spanning tree.
