5-30
Chapter 5
Cajun P550/P880/P882 Switch User Guide
Configuring Switch Port Parameters
You can configure how each switch port performs its switching
functions (for example, VLAN parameters, hunt group assignments,
trunk mode, and frame tag scheme) through the switch port
parameters.
You can configure switch port parameters using either the web
agent or the CLI.
Configuring
Switch Port
Parameters
Using the Web
Agent To configure switch port parameters using the web agent:
1. Select Configuration from the Modules & Ports group on the
web agent window. The Module Information dialog box
opens (Figure 5-7).
2. Select the checkbox in the Slot column for the module on
which you want to configure the switch ports.
3. Select the switch ports for that module from the Switch Ports
column. The Switch Ports dialog box opens
(Figure 5-10).
4. Select a port name from the Name column. The Switch Port
Configuration dialog box opens (Figure 5-11).
