Cajun P550/P880/P882 Switch Configuration Guide
Configuring AppleTalk Routing
15-31
2. Refer to Table 15-9 for a definition of the AppleTalk ARP
Cache Table parameters.
3. Select the checkbox next to any specific ARP entries that you
want to delete and click Delete Entries.
or
Click Flush Route Table to reset the ARP cache table
entries. Only Dynamic and Router Neighbor entries are
flushed.
Viewing the
AppleTalk ARP
Cache Table
Using the CLI To view the AppleTalk ARP cache table using the CLI, enter the
following command from User mode:
> show appletalk arp [all]
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about these commands.
Table 15-9. AppleTalk ARP Cache Table Parameters
Parameter Definition
Select Select the table entry to be acted upon.
Network Range Displays the network range.
Node Displays the node number for the entry.
MAC Address Displays the MAC address associated with the
AppleTalk ARP cache table entry of the node.
Interface Displays the AppleTalk interface associated with the
AppleTalk ARP cache table entry.
Type Displays the type of cache entries.The values are:
• Local
• Broadcast
• Dynamic
• Router Neighbor
TTL Displays the time-to-live value for the selected
AppleTalk ARP cache table entry. Local and
Broadcast entries do not time out.
