9-66
Chapter 9
Cajun P550/P880/P882 Switch User Guide
7. Refer to Table 9-29 for an explanation of the DVMRP
Downstream Links dialog box parameters.
8. Select the number in the Upstream Source(s) field. The
DVMRP Upstream Source(s) dialog box opens.
9. Refer to Table 9-30 for an explanation of the DVMRP
Upstream Source(s) dialog box parameters..
Table 9-29. DVMRP Downstream Links Dialog Box Parameters
Parameter Displays the...
Destination Group Address Destination group address.
Source SubNetwork Source subnetwork.
DVMRP Downstream
Interface DVMRP Downstream interface.
Interface Type Interface type. Types include:
• Broadcast - All traffic is forwarded through
the routers. This is not a tunnel and does not
require encapsulation.
• IPIP Tunnel - All multicast traffic (data and
protocol messages) on this interface is
encapsulated in IP unicast packets with the
protocol set to IPIP (IP in IP).
• Non-Encapsulated Tunnel - All multicast
data traffic on this interface is IPIP
encapsulated, but the protocol messages are
simple unicast.
Interface is Pruned Status of whether the interface has been pruned.
Prune Expiration in (sec) Time (in seconds) that the interface times out
waiting for the prune message to expire.
Table 9-30. DVMRP Upstream Source(s) Dialog Box Parameters
Parameter Displays the...
Destination Group
Address Destination group address for the upstream interface.
Flow Source Address Host source address for the upstream flow.
Flow Upstream
Interface Name of the flow source interface.
Payload Protocol Type Protocol type for the payload.
Source Port Number Source port number.
Destination Port
Number Destination port number.
