AT-WA7500 and AT-WA7501 Installation and User’s Guide
57
2. Connect the access point to your network as shown in the next two
illustrations.
Note
The patch cord shown above must connect to the access point with
a female MT-RJ connector. For details, see “Using and Purchasing
the Required Patch Cord and Adapter” on page 55.
Note
The patch cord shown above must connect to the access point with
a female MT-RJ connector. For details, see “Using and Purchasing
the Required Patch Cord and Adapter” on page 55.
SC connector
To SC
network
SC connector
SC adapter
Female
MT-RJ connector
Patch cord
To access point
SC connector
To SC
network
To SC
network
SC adapter
SC connector
Female
MT-RJ connector
Patch cord
To access point
