AT-WA7500 and AT-WA7501 Installation and User’s Guide
35
7. Configure the spanning tree settings for the point-to-point bridge on the
primary LAN:
a. From the main menu, click Spanning Tree Settings. The Spanning
Tree Settings screen appears.
b. In the Root Priority field, enter a number other than 0.
c. In the Secondary LAN Bridge Priority field, enter 0.
d. In the Secondary LAN Flooding field, choose Disabled.
8. If the roaming end devices will be roaming across an IP router, you
must configure IP tunnels. For help, see “Configuring IP Tunnels” on
page 148.
9. Click Submit Changes to save your changes. To activate your
changes, from the menu bar click Save/Discard Changes, and then
click Save Changes and Reboot. For help, see “Saving Configuration
Changes” on page 45.
Example - Configuring an 802.11g Bridge
In this example, each access point only has one 802.11g radio. Since the
designated bridge only has a station radio, wireless end devices can only
communicate with the root access point. However, wired devices on the
secondary LAN can communicate with the primary LAN.
Figure 14. 802.11g Bridge
Primary LAN Secondary LAN
Root
Host
Designated
bridge
