Allied Telesis AT-WA7501 User Manual
Page 20
Chapter 1: Getting Started
20
This illustration shows the ports that are on the AT-WA7501. For help
understanding these ports, see the Port Descriptions table on page 19.
Figure 4. AT-WA7501 Ports
Power port
(optional)
10BaseT/
100BaseTx
Ethernet port
Fiber optic
port (optional)
Serial
port
Cable
access
door
