AT-WA7500 and AT-WA7501 Installation and User’s Guide
21
The AT-WA7500 ports are located on the bottom of the access point. This
illustration shows the ports that are on the AT-WA7500. For help
understanding these ports, see the Port Descriptions table on page 19.
Figure 5. AT-WA7500 Ports
For more information on connecting the ports, see Chapter 2, “Getting
Started” on page 11.
Serial port
10BaseT/100BaseTx
Ethernet port
