Chapter 7: LACP Port Trunks
88
Here is how the example looks in a table format.
Caution
The example cited here illustrates a loop in a network. Avoid
network loops to prevent broadcast storms.
If the aggregate trunks go to different devices, you can create one
aggregator and the AT-GS950/8POE switch forms the trunks
automatically. This is illustrated in Figure 27 where the ports of two
aggregate trunks on the AT-GS950/8POE switch are members of the
same aggregator. It is the switch that determines that there are two
separate aggregate trunks.
Figure 27. Example of an Aggregator with Multiple Trunks
Aggregator Description
Aggregator Ports
Aggregate Trunk Ports
Aggregator 1
1-3
1-3
Aggregator 2
6-8
6-8
1385
AT-GS950/8POE
8 Port 10/100/1000Mbps + 2 SFP Combo WebSmart Switch
SFP
SFP
CLASS 1
LASER PRODUCT
1
2
3
4
5
6
7R
7
8
8R
POWER
RESET
1
2
3
4
5
6
7R
8R
7
8
POE
100/1000Base-X
PORT ACTIVITY
ACT
1000 LINK
100 LINK
ACT
ACT
SFP
1
3
5
7
9
11
13
15
17
19
21
23
2
4
6
8
10
12
14
16
18
20
22
24
LINK
MODE
LINK
MODE
COL
100
FULL
ACT
FAULT
RPS
MASTER
PWR
MODE
1
3
5
7
9
11
2
4
6
8
10
12
13
15
17
19
21
23
14
16
18
20
22
24
STATUS
26
25
AT-8524M
Fast Ethernet Switch
AT-GS950/8POE
Switch
Aggregate Trunks
in Common Aggregators
Ports 1 - 3 and 6-8
in Aggregator 1
802.3ad-compliant
Server
802.3ad-compliant
Ethernet Switch
