AT-S101 Management Software User’s Guide
141
Figure 43. Point-to-Point and Edge Port
Determining whether a bridge port is point-to-point, edge, or both, can be a
bit confusing. For that reason, do not change the default values for this
RSTP feature unless you have a good grasp of the concepts. In most
cases, the default values work well.
1368
AT-GS950/8POE 8 Port 10/100/1000Mbps + 2 SFP Combo WebSmart Switch
SFP SFP
CLASS 1 LASER PRODUCT
1 2 3 4 5 6 7R 7 8 8R POWER RESET
1 2 3 4 5 6 7R 8R
7 8
POE
100/1000Base-X
PORT ACTIVITY
ACT
1000 LINK
100 LINK
ACT
ACT
SFP
Point-to-Point and Edge Port
Workstation
(Full-duplex Mode)
