AT-S101 Management Software User’s Guide
163
Figure 50. Port-based Authentication Across Multiple Switches
1371
AT-GS950/8POE 8 Port 10/100/1000Mbps + 2 SFP Combo WebSmart Switch
SFP SFP
CLASS 1 LASER PRODUCT
1 2 3 4 5 6 7R 7 8 8R POWER RESET
1 2 3 4 5 6 7R 8R
7 8
POE
100/1000Base-X
PORT ACTIVITY
ACT
1000 LINK
100 LINK
ACT
ACT
SFP
AT-GS950/8POE 8 Port 10/100/1000Mbps + 2 SFP Combo WebSmart Switch
SFP SFP
CLASS 1 LASER PRODUCT
1 2 3 4 5 6 7R 7 8 8R POWER RESET
1 2 3 4 5 6 7R 8R
7 8
POE
100/1000Base-X
PORT ACTIVITY
ACT
1000 LINK
100 LINK
ACT
ACT
SFP
Switch A
Switch B
Supplicants with
802.1x Client Software
Ports 1 to 4:
802.1x Port Control
Setting: Auto
Port 6: 802.1x Port Control
Setting: Force-authorized
RADIUS
Authentication
Server
Port 8:
802.1x Port Control
Setting: Force-authorized
Port 7:
802.1x Port Control
Setting: Force-authorized
