AT-S101 Management Software User’s Guide
57
Modifying a Port-Based VLAN
To modify the name or port assignments of a port-based VLAN, perform
the following procedure:
1. From the menu on the left side of the page, select Bridge.
The Bridge folder expands.
2. From the Bridge folder, select VLAN.
The VLAN folder expands.
3. From the VLAN folder, select Port-Based VLAN.
The Port-Based VLAN Page is shown in Figure 19 on page 56.
4. In the VLAN Action column, click modify next to the VLAN that you
want to change.
The Modify Port-based VLAN Page is shown in Figure 20.
Figure 20. Modify Port-based VLAN
5. To change the name of the VLAN, type in a name in the VLAN Name
field.
Enter a value of up to 32 characters.
6. To assign ports to the VLAN, click on the port numbers labeled either
Group Member or Not Member. Then click Apply.
