Chapter 3: Virtual LANs
56
Creating a Port-Based VLAN
To create a port-based VLAN, perform the following procedure:
1. From the menu on the left side of the page, select Bridge.
The Bridge folder expands.
2. From the Bridge folder, select VLAN.
The VLAN folder expands.
3. From the VLAN folder, select Port-Based VLAN.
The Port-Based VLAN Page is shown in Figure 19.
Figure 19. Port-Based VLAN Page
4. To assign a VLAN ID, type a VLAN ID in the VLAN ID field.
Choose a value between 1 and 52.
5. To assign a name to a VLAN, type in a name in the VLAN Name field.
Enter a value of up to 32 characters.
6. To assign ports to the VLAN, click on the port numbers labeled Group
Member. Then click Apply.
7. From the menu on the left side of the page, select Save
Configuration to Flash to save your changes.
