Switch PIC
A card in the 6780 switch that plugs into the switch logic board. Most switch PICs (except for maintenance PICs and
router interconnect PICs) are populated with transceivers that enable connections to the different nodes, layers, and
zones of the cluster.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch PIC
Example: Switch PIC $ZZSMN.Y11.13 (1011.1.13)
See also Router Connections for Router Interconnect PICs .
Attributes
Switch PIC
Displayed in the Attributes tab and Attributes dialog box only if the value is something
other than OK.
Values
Service State
Physical
The type of PIC.
Values: Single-mode fiber-optic, Multimode fiber-optic, Router Interconnect,
Maintenance, Dual Single-mode fiber-optic, Quad Multimode fiber-optic Model
The part number of the switch PIC. Part Number
Whether the PIC is installed and responding. Presence
The state of the fault LED on the switch PIC.
Values: On, Off, Blinking LED State
The track ID of the switch PIC. Track ID
Identifies the manufacturer of the component. Manufacturer
The hardware revision of the switch PIC. Hardware Revision
Logical
The initial state of the component at the time of discovery.
Enabled: The component is operational.
Disabled: The component is present but not operational.
Enabled State
Indication of whether the switch has a fault.
Values: OK, Fault Device State
Actions
Blink LED Off
Turns off the blinking of the LEDs.
Blink LED On
Causes the LEDs to blink on and off.
Replace
Invokes the Replace Switch Component guided procedure that helps to replace the switch PIC.
