External ServerNet Fabric
This object represents a collection of switches and ServerNet links that connect the local node to other nodes in a
ServerNet cluster.
Location in OSM tree:The External ServerNet Fabrics (X and Y) are under the ServerNet Cluster.
Example:External ServerNet X Fabric
Attributes
External ServerNet X Fabric
Displayed in the Attributes tab and Attributes dialog box only if the value is something
other than OK.
Values
Service State
Logical
The number of nodes that are currently connected to the ServerNet cluster on this
fabric, including the local node to which you are currently logged on. Number of Nodes
The connectivity state between processors on the local node and processors on
remote nodes for this fabric.
Up: At least one processor on the local node can communicate with a processor on
one of the remote nodes.
Down: No processor on the local node can communicate with a processor on any
remote node. This value is the default.
Fabric State
Actions
Node Connectivity ServerNet Path Test
Checks the local node's connection to the ServerNet cluster by testing the external fabric (X or Y) between the MSEB
on the local node and the cluster switch on the fabric.
244 Cluster Resources
