ServerNet Switch Board

A component of the

IOAM

, the ServerNet Switch Board provides ServerNet connectivity between processors, ServerNet

adapters, and attached hardware devices.

OSM software communicates with an internal part of the switch known as the Maintenance Entity (ME) by a connection
established through the

Maintenance Switch

.

Location in OSM Tree:

In an IOAM: System > Group > IOAM Enclosure > IOAM > ServerNet Switch Board

Example: ServerNet Switch Board (11.2.14)

Attributes

ServerNet Switch Board

Displayed in the Attributes tab and Attributes dialog box only if the value is something
other than OK.

Values

Service State

Physical

A code that identifies the generation of the component. Hardware revision codes are
used for tracking components.

Hardware Revision

Indicates whether the ServerNet Switch Board LED is on or off.

LED State

Identifies the manufacturer of the component.

Manufacturer

The part number of the component that was assigned in manufacturing. Use part
numbers for identifying and ordering parts.

Part Number

A unique serial number that identifies the component. Track IDs are used for tracking
components.

Track ID

Logical

The date and time of the last hard or soft reset of the ServerNet Switch Board.

Time of Last Reset

This attribute is displayed only within the Multi-Resource Actions dialog box, to
indicate whether the ServerNet Switch Board is on the X or Y fabric.

Fabric Side

ME FPGA

The VPROC of the ME FPGA (Field Programmable Gate Array) image currently
loaded on the switch logic board.

Version

The full path name of the default ME FPGA file on the server.

Default File Name

The version of the ME FPGA image in the default FPGA file.

Default File Version

The differences, if any, between the current and default ME FPGA versions.

Values

Compare State

ME Firmware

The version of the ME firmware running on the switch board.

Version

The name of the file to be used for a firmware update.

Default File Name

The version of the firmware to be used for a firmware update .

Default File Version

The differences, if any, between the current and default firmware versions.

Values

Compare State

Actions

Dump Memory

Dumps a snapshot of the ServerNet Switch Board's logic board memory, created by the

Enable Memory Snapshot

action, to a file in $SYSTEM.ZSERVICE.

You can view the filename in the Action Detail dialog box for this action.
