Physical Location
The values displayed by these attributes are assigned through the Set Physical Location action.
NOTE: These attributes are not displayed for a VIO Module providing V4SE or V8SE connectivity (NS16000CG or
NS5000).
A user-defined name assigned to identify the rack in which the VIO enclosure is
located. You can enter up to eight alphanumeric characters. Rack Name
A number (from 1 to 42) assigned to describe the location of the VIO enclosure within
the rack. Rack Offset
An optional text string assigned to further identify the physical location of the VIO
enclosure.
This attribute is displayed only if a value is specified using the Set Physical Location
action. Locator
For DC-powered Telco systems only.
This attribute should not appear for VIO enclosures, as it displayed only if a value is
specified through the
Set Physical Location action.
Alarm Panel Identifier
Actions
Read LCD
Displays all 16 lines of the VIO enclosure’s LCD text in the Action Detail dialog box.
Replace
Displays a service procedure describing how to replace a VIO enclosure.
Retrieve Network Connectivity Info
Displays remote IP addresses stored in the IPAUTH file.
NOTE: Not valid for S-series servers.
Set Physical Location
Allows you to assign these Physical Location attributes for the VIO enclosure:
•
Rack Name is a user-defined name for the rack containing the VIO enclosure. You can enter up to eight
alphanumeric characters.
•
Rack Offset is a numerical value representing the location of the VIO enclosure within the rack. A valid integer
(from 1 to 42) must be specified when performing the Set Physical Location action, or the action will fail.
•
Locator is an optional text string to help identify the physical location of the VIO enclosure. It must contain
alphanumeric characters only.
•
This parameter should be left blank, as it is used for DC-powered Telco systems only, which do not support VIO
enclosures.
Synchronize FIR Files
Synchronizes the FRU information record (FIR) files of the X and Y fabric processor switches.
NOTE: Not valid for S-series servers.
Write LCD Line
Allows you to edit the text displayed by the VIO enclosure’s LCD. You can modify lines 9 through 15 with this action.
