ServerNet Local Node
This object represents the system within a ServerNet cluster to which you are currently logged on.
Location in OSM tree: Under the ServerNet Cluster
Example: ServerNet Local Node \STARZ
Attributes
ServerNet Local Node
Displayed in the Attributes tab and Attributes dialog box only if the value is something
other than OK.
Values
Service State
Logical
The state of the connection from the local node to the remote node over the external
ServerNet Y fabric.
Up: At least one of the processors on the local node can communicate with at least
one processor on a remote node over the Y fabric.
Down: No processor on the local node can communicate with any processor on the
remote node over the Y fabric.
Unknown: The state of the connection cannot be determined.
Y Fabric Connection State
The Expand node number of the local node.
Value: 0 through 254
Expand Node Number
The ServerNet node number of the local node.
Value: 1 through 96
ServerNet Node Number
The state of the connection from the local node to the remote node over the external
ServerNet X fabric.
Up: At least one of the processors on the local node can communicate with at least
one processor on a remote node over the X fabric.
Down:No processor on the local node can communicate with any processor on the
remote node over the X fabric.
Unknown:The state of the connection cannot be determined.
X Fabric Connection State
Actions
Generate ServerNet Statistics
Generates an event containing the ServerNet statistics from the remote node to the local node.
248 Cluster Resources
