E4SA (Ethernet 4 ServerNet Adapter)
An adapter that connects the ServerNet connections inside a server to an Ethernet local area network (LAN). The
Ethernet 4 ServerNet Adapter (E4SA) CRU contains two Ethernet ServerNet addressable controllers (SACs), each
of which contains two Ethernet physical interfaces, for a total of four Ethernet ports on each E4SA CRU.
Location in OSM Tree: System > Group > Module > E4SA
Slot Location: E4SA CRUs can be located in slots 53 and 54 in processor enclosures (service side) or in slots 51, 52,
53, and 54 in IOMF or IOMF2 enclosures (service side).
Example: E4SA $ZZLAN.E4SA0 (1.1.53)
Attributes
E4SA
Displayed in the Attributes tab and Attributes dialog box only if the value is something other than
OK.
Values
Service State
Physical
A code that identifies the generation of the component. Hardware revision codes are used for
tracking components. Hardware Revision
Identifies the manufacturer of the component. Manufacturer
The part number of the component that was assigned in manufacturing. Use part numbers for
identifying and ordering parts. Part Number
Indication of whether the component is powered On or Off. Power State
A unique serial number that identifies the component. Track IDs are used for tracking components. Track ID
Logical
Which, if any, ServerNet router ports on this CRU are disabled. OSM actions to disable or enable
a ServerNet port are performed as directed by OSM alarm repair actions. Disabled ServerNet Ports
The configuration type of this resource.
Value: CCSA, E4SA, FESA, G4SA, GESA, TRSA, Unknown Configured Type
The state of the component as known to the operating system on the server. Values Device State
Actions
Abort
Terminates operation of the Ethernet 4 ServerNet Adapter (E4SA) CRU and the associated Ethernet ServerNet
addressable controller (ESAC). When the Abort action finishes, the E4SA CRU and the ESAC are in the Stopped
state.
Disable ServerNet Port
Disables the specified ServerNet router port on this CRU. Perform this action only as directed by OSM alarm repair
actions.
Parameter: Port Number
Enable ServerNet Port
Enables the specified ServerNet router port on this CRU. Perform this action only as directed by OSM alarm repair
actions.
Parameter: Port Number
Start
Starts the Ethernet 4 ServerNet Adapter (E4SA) CRU and the associated Ethernet ServerNet addressable controller
(ESAC). The E4SA CRU and the ESAC must be in the Stopped state before you perform this action.
During startup, the controller operational code is automatically loaded into the ESAC. When the Start action completes,
both the E4SA CRU and the ESAC are in the Started state.
E4SA (Ethernet 4 ServerNet Adapter) 109
