Logger
Settng Up FTP and E-mal
10. For FTP settings, click the FTP tab. For e-mail settings, click the E-mal tab. For
instructions on settings, see the FTP Settings or E-Mail Setting items in this section.
Click the Condition tab.
Select to perform an action when data
dropouts are detected
Select to enable
Select to perform an action when
communication reconnection is detected
Select to perform an action when broken
communication is detected
Click here.
Click the Process tab.
Select to send unit information files by FTP
Select to add unit information to the body of
the e-mail
Select to add message to the body of the e-mail
Settng Start Record Events
1. Click Start Record. The screen changes to the Start Record Event setting screen.
Enterng Condtons
2. Click the Condton tab.
3. If the check box in the Acton space is selected, the event becomes active.
Process Settngs
6. Click the Process tab.
7. Select the The Fle s set wth FTP check box in the Event Processng space to
send user files via FTP.
8. Select the Sendng E-Mal check box in the Event Processng space and select the
User Fle
check box under Attach File to send user files as an e-mail attachment.
9. In the Sendng E-Mal item in the Event Processng space, select the User Fle
and Message check boxes under Body
to copy the contents of the user file to the
body of an e-mail message, and send the message.
2.9 Event Processng
