Logger
Settng the Intal Balancng for Stran Input Channels (Only When the Input
Mode Is Set to STR)
18. Click the Intal Balance button under Stran, or the Execute button under Reset.
The Executng Intal balancing dialog box appears, and Executng is displayed in
the Status box. When Executon is complete, the result is displayed in the Status
box.
Set the initial balance for strain input channels (only when the input mode is set to STR)
Note
• You can execute initial balancing and reset the initial balance value on multiple recording
channels at once by selecting the channels and clicking the Execute All button.
Collective execution ON/OFF button
Channel on which to perform initial
balancing to select them
Selected channels are displayed with red
characters against a gray background
• To execute initial balancing on a strain input module, you must enter channel settings and
send them. Therefore, if invalid channel settings are entered, a dialog box will appear
prompting you to correct the settings.
2.4 Settng the Measurement Condtons (Measurement Channel Settngs)
