Cal
brator
Explanaton
Calbrated Parameters
• 4-CH, High-Speed Universal Input Module (MX110-UNV-H04)
Measurement Range to Be Calbrated Input Value 1 Input Value 2
20 mV 0 mV 20 mV
60 mV 0 mV 60 mV
200 mV 0 mV 200 mV
1 V 0 V 1 V
2 V 0 V 2 V
6 V 0 V 6 V
20 V 0 V 20 V
100 V 0 V 100 V
RTD (1 mA) 200 mV 0 Ω 200 Ω
RTD (1 mA) 600 mV
0 Ω 300 Ω
RTD (1 mA) 1 V 0 Ω 500 Ω
RTD (2 mA) 60 mV
0 Ω 30 Ω
RTD (2 mA) 200 mV
0 Ω 100 Ω
RTD (2 mA) 600 mV 0 Ω 300 Ω
RTD (2 mA) 1 V
0 Ω 250 Ω
• 10-CH, Medium-Speed Universal Input Module (MX110-UNV-M10)
Measurement Range to Be Calbrated Input Value 1 Input Value 2
20 mV 0 mV on Ch1 20 mV on Ch2
60 mV 0 mV on Ch1 60 mV on Ch2
200 mV 0 mV on Ch1 200 mV on Ch2
1 V 0 V on Ch1 1 V on Ch2
2 V 0 V on Ch1 2 V on Ch2
6 V 0 V on Ch1 6 V on Ch2
20 V 0 V on Ch1 20 V on Ch2
100 V 0 V on Ch1 100 V on Ch2
RTD (1 mA) 60 mV
0 Ω on Ch3 60 Ω on Ch6
RTD (1 mA) 200 mV
0 Ω on Ch3 200 Ω on Ch4
RTD (1 mA) 600 mV 0 Ω on Ch3 300 Ω on Ch5
• 30-CH, Medium-Speed DCV/TC/DI Input Module (MX110-VDT-L30)
Measurement Range to Be Calbrated Input Value 1 Input Value 2
20 mV 0 mV on Ch1 20 mV on Ch2
60 mV 0 mV on Ch1 60 mV on Ch2
200 mV 0 mV on Ch1 200 mV on Ch2
1 V 0 V on Ch1 1 V on Ch2
2 V 0 V on Ch1 2 V on Ch2
6 V 0 V on Ch1 6 V on Ch2
20 V 0 V on Ch1 20 V on Ch2
100 V 0 V on Ch1 100 V on Ch2
RTD (1 mA) 60 mV 0 Ω on Ch3 60 Ω on Ch6
RTD (1 mA) 200 mV
0 Ω on Ch3 200 Ω on Ch4
RTD (1 mA) 600 mV
0 Ω on Ch3 300 Ω on Ch5
4.2 Calbraton Procedure
