3-6
IM WX103-01E
3.2
Settng the Dsplay
Procedure
Changng the Dsplay on the Waveform Dsplay Wndow
Change the display settings according to the explanation is the figure below.
Switch the display group
Y-axis
Channel ON/OFF
Change the grid density
Channel number and measurement unit
Change the background
darkness
Zoom in or out of the time axis
Switch the display zone
Switch the active channel
Alarm display ON/OFF
Move the cursor to the point where
the alarm changed
Clip display ON/OFF
Switch the grid density
Zone display section ON/OFF
Changng the Dsplay Usng the Toolbar
Change the display settings according to the explanation is the figure below.
Show the window for displaying statistical
computation over an area
Show the General Display
Settings window
Show the window for displaying cursor values
Show the numeric display window
Alarm/marker list display
Show the waveform display window
Switching between Absolute and Relative time
Move cursor A to the right mark
Move cursor A to the left mark
Move cursor B to the left mark
Move cursor B to the right mark
Tag comment display
Tag No. display
Channel number display
Add a mark
