1-14 IM WX103-01E
• Meter Montor
Numeric
display
Unit
Channel color
Channel
number
Alarm indication Click here.
Displays a red bar on the group with an alarm occurring
Switch between channel number,
tag No., and tag comment
Thermometer Bar meter Analog meter
• All Channel Montor
Click here.
Zoom in or out of the time axis
Turn ON/OFF the waveform
display limit
Monitor Interval
Change the grid density
Change the background
darkness
Change the grid thickness
Switch the thickness of the
waveform
The All Channel Monitor screen opens.
1.2 MXLOGGER Operaton Gude
