5.2 Error Messages and Ther Correctve Actons
Error Messages on the Logger
Code Message Correctve Acton/Descrpton Reference Page
– Undetermined Directory. The save destination of the record file cannot be found.
Check whether the save destination exists. 2-11
E5501 Recording or Working. Try again once recording stops. 1-22
E5502 Cannot open file.Check viewer. If a dialog box is open in the Viewer, close it. –
E5503 It failed in acquisition of CF
information. Please verify the usage
condition of the equipment Check whether the host name is correct, and whether the
main unit is connected. 2-6
E5504 Failed to get channel and network
configuration. Check the disk capacity and whether the file system is
correct. 2-6
E5505 Failed to get information. Check
connecting MX. Check the disk capacity and whether the file system is
correct. 2-6
E5506 Failed to create folder. Check the disk capacity and whether the file system is
correct. –
E5507 Invalid folder name.
Please enter a new name.
Specify a valid folder name. –
E5508 Cannot contain any of the following
characters:\n \\ / : , ; * ? " < > |\nCON
PRN AUX CLOCK$ NUL COM1-9
LPT1-9 Use characters other than the following: “ \\ /: , ; * ? " < >
|CON PRN AUX CLOCK$ NUL COM1-9 LPT1-9” –
W5531 The current channel setup contains
invalid use of reference channels.
Channels whose mode is set to RRJC.
Channels used for difference input.
Transmission AO channels.
Transmission PWM channels.
Do you wish to continue after
disabling the invalid channels?
Click No and change the settings of inappropriate
channels.
To disable the inappropriate channels, click Yes. 2-20 to 2-23
W5532 In order to balance the strain
channels, it’s necessary for channels
to be set up correctly.
The current channel setup contains
invalid use of reference channels.
Some measurement channels set to
RRJC mode.
Channels used for difference input.
Transmission AO channels.
Transmission PWM channels.
Do you wish to continue after
disabling the invalid channels?
Click No and change the settings of inappropriate
channels.
To disable the inappropriate channels, click Yes. 2-20 to 2-23
W5533 Invalid modules exist. do you get
configuration after reconstructing?
Click OK to reconfigure the system based on the
information acquired from the main unit. 1-6
M5561
Stop record?
Click OK to stop recording. 2-74
M5562
Stop monitoring and quit?
Click OK to stop acquisition. 2-76
M5563 Assign all modules to appropriate
measuring groups?
Click OK to assign automatically. 1-6
M5564 Please wait until writing of data is finished. –
M5565 Restart the monitor server to apply the changed port
number. 2-79
M5566 State: Active
Max.: □□□ bytes
Free: □□□ bytes
– 2-9
M5567 Check whether the CF card is formatted. –
M5568 Insert a CF card. *
M5569 Apply the edited network
configuration of MXs?
Click OK to send settings. 2-3
M5570
Modules of Slot□ - Slot□ will be
changed. Ok to continue?
Click OK to change the specified module. Cancel to return
to the previous screen. 2-6
* See the
MX100 User’s Manual (IM MX100-01E).
