32
Merlin II Protocol Analyzer User’s Manual CATC SW Version 2.50
4.3 Status Bar
The Status Bar is located at the bottom of the main display window.
Depending on the current activity, the bar can be divided into as many as
four segments. The figure below demonstrates the various displays in the
status bar.
Recording Progress
When you begin recording, the left-most segment of the Status Bar displays
a Recording Progress Indicator. The following figure displays the various
indications of the status bar:
Status Bar Position Definitions:
The following numbered definitions correspond to the number labels on the
above status bars.
1 Analyzer is connecting to the host machine.
2 Analyzer was disconnected from the host machine.
3 Analyzer is connected to the host machine.
Decodes protocols for the A2DP profile.
Decodes protocols for the BIP profile.
Decodes protocols for the BIP profile.
