157
Merlin II Protocol Analyzer User’s Manual CATC SW Version 2.50
To view two or three graphs simultaneously, click the Graph Areas button.
A menu opens with the following graph options:
• General Statistics - Shows/hides stats on right side of window.
• Packet Occurrence (Rate)
• Packet Occurrence (Accumulation)
• Errors Occurrence (Rate)
• Retransmissions - This graph shows the rate of retransmitted
packets. In the Real-Time Statistics, a packet is evaluated as
'retransmitted' if at least one non-FHS seqn bit has already been
received and if the previous sequence bit is the same as the
current sequence bit. As the sequence bit toggles on data
payloads carrying CRC, the Real-Time Statistics tracks the seqn
bits in DM, DV, DH payload, and checks for correctness only if
the payload was correctly decoded without errors.
11.8 File Information
The File Information report provides valuable information about how the
recording was made, what the buffer settings were, what the trigger options
were, and what version of all the analyzer hardware was used to make the
recording.
To display a File Information report,
• Select File Information under Report in the Menu Bar
OR
Click in the Tool Bar.
You see the File Information screen:
