To open a trace,

Step 1

Select File > Open from the menu. A dialog box opens.

Step 2

Select a file from the dialog box and click Open. A trace opens in
the main viewing area. When traffic has been recorded, it will
display here.

Note

The software may be used with or without the analyzer box. When used without
an analyzer box attached to the computer, the program functions as a Trace
Viewer to view, analyze, and print captured protocol traffic.
