174

Merlin II Protocol Analyzer User’s Manual

CATC

SW Version 2.50

The following is the WAVE file format that is used by the 'Export Audio
Streams' functionality to generate the audio files. The right-most column
describes the data as being put by the CATC Bluetooth analyzer application.

Field Name

Endian

File
Offset

Field Size

Field Description

CATC Data

ChunkID

Big

0

4

Contains the letters
"RIFF" in ASCII form

(0x52494646 big-endian
form).

RIFF stands for
"Resource Interchange
File Format."

"RIFF"

ChunkSize

Little

4

4

36 + SubChunk2Size, or
more precisely:

4 + (8 + SubChunk1Size)
+ (8 + SubChunk2Size)

This is the size of the
entire file in bytes minus
8 bytes for the two fields
not included in this
count: ChunkID and
ChunkSize.

Calculated when
file is created.

Format

Big

8

4

Contains the letters
"WAVE" (0x57415645
big-endian form).

“WAVE”

Field Name

Endian

File
Offset

Field Size

Field Description

CATC Data

Subchunk1ID

Big

12

4

Contains the letters "fmt"
(0x666d7420 big-endian
form).

‘f’, ‘m’, ‘t’, ‘’

Subchunk1Size

Little

16

4

16 for PCM. This is the
size of the rest of the
Subchunk, which follows
this number.

0x12

AudioFormat

Little

20

2

PCM = 1 (i.e. Linear
quantization)

Values other than 1
indicate some form of
compression.

1

NumChannels

Little

22

2

Mono = 1, Stereo = 2,
etc.

Num of actual
channels as
selected by the
user: 1 or 2.
