Merlin II Protocol Analyzer User’s Manual CATC SW Version 2.50
Intersection is used to search for all selected events: "Find x and y."
Intersection lets you tell the analyzer to search the trace for any packet
having all of the selected events.
Exclusion is used to exclude selected traffic from the trace. Exclusion is
used with Union and Intersection --i.e., you select Exclusion with Union or
Intersection.
• Exclusion + Union -- tells Merlin II to exclude packets with any of the
specified events.
• Exclusion + Intersection -- tells Merlin II to exclude packets with all of the
specified events.
Using Find
Step 1
Select the display level to be searched from the Search For
box on the left side of the window.
For example, to search through L2CAP messages, select L2CAP. The display
level that you select will affect options presented in the Events Group box.
Step 2 Select a search direction and origin.
Step 3 Select one or more events from the Events Group box.
Your choices will affect options presented in the box on the right side of the
screen.
Step 4 If you have selected two or more criteria, then select either :
•
Union: Find all packets that match ANY of the specified events. An
example would be to find packets with either X or Y.
•
Intersection: Find all packets that match ALL of the specified
events. An example would be to find all packets with X and Y.
If you want to selected events from the trace, then select:
•
Exclusion: Exclude all packets that match any of the specified
events. This option works in conjunction with Union and Intersection.
Select an exclusion plus one of the other two options. If you select
Exclusion and Union, it means Exclude packets in any of the
following events. An example would be to exclude packets with
either X or Y.
