9
Merlin II Protocol Analyzer User’s Manual CATC SW Version 2.50
2. Installation
The Merlin II Protocol Analyzer components and software are easily
installed and quickly ready to run on most Windows-based personal
computer systems. You can begin making Bluetooth recordings after
following these initial steps.
2.1 System Components/Packing List
• One stand-alone Merlin II Analyzer
• One Antenna
• One External Interface Breakout Board with a Mini DIN cable
• One External Power Supply
• One PS/2 Power Cable
• One USB cable
• Merlin II software program installation CD
• User’s Manual
2.2 Analyzer LED Descriptions
The Merlin II analyzer has three LEDs. From left to right, these LEDs are:
A Blue Status indicator LED Blinks fast during initialization/power up.
Stead on if unit is functioning properly. Blinks slowly if a self-test fails..
B Yellow Sync (Synchronize) LED (Flashing indicates that the analyzer is
tracking the defined slave or master device. Illuminated indicates that
the analyzer is tracking an active piconet.)
C Green Rec (recording) LED (lights when the unit is recording).
2.3 Rear Panel Description
USB type "B" host computer connector
This connector links the analyzer to the PC that will be administering it.
Mini DIN Connector
This connector allows the analzyer to transmit and receive external signals
via a mini DIN cable to a Break Out Board for the purpose of triggering on
external input signals and for clock calibration.
